Markem-Image 5940G LCIJ
Model: 5940G LCIJ
Highest quality codes for GS1 compliance
including GS1-128 and Digital Link for C grade or better barcodes, trust our Touch Dry® inks that solidify on contact, unlike liquid inks that lose resolution by spreading along corrugate fibers.
Ensuring safety and enabling sustainability
Our Touch Dry® inks are non-hazardous, 100% Solvent Free. MEK Free, odorless and have No V.O.C.s (Volatile Organic Compound) comply with global food packaging guidelines and are supplied in recyclable PP-Polypropylene containers.
Efficiency and data integrity through greater automation
The 5940 G supports 1D and 2D scanners for lookup and verification, comes standard with five inputs and five outputs, all programmable. Simple integration with PLCs and enterprise databases.
Features
- Print Area 2.56″ max print height w/ a single print head
- Print Density: Available densities 1 to 10
- Print speed: 24 m/min up to 182 6.6 m/s application / density dependent
- Print Heads: Choose one, two, three, or up to four printheads
- Wide choice of 1D and 2D barcodes: ITF, Code 39, Code 128, GS1-128, EAN 128, EAN 8, EAN 13, UPC-A, UPC-E, DataMatrix, RSS linear, RSS composite, QR, RSS 14, RSS expanded, PDF 417
- Print Fonts: Full TrueType fonts supported
- Real-Time Clock: Printing of real-time clock (hr/min/sec), dates and auto updating best before dates and serial numbers
Machine Specifications
- Weights Painted Steel (Standard):
– Printhead (PH): 2.1 kg / 4.7 lbs
– Controller: 1/2 PH – 50 kg. / 111 lbs., 3/4 PH – 52.6 kg. / 116 lbs.
– Controller base with castors: 17.5 kg / 38.9 lbs - Mounting: Table-top or vertical
- Umbilic: 2.7-meter cable
- Construction: Painted Steel w/ option for Stainless steel cabinet
- Electrical and environmental:
– 1-2 PH systems 90-240 VAC, 50/60 Hz
– 3-4 PH systems 200-240 VAC, 50/60 Hz
• Operating environment of 0 to 40° C (32 to 104° F)
• Standard Cabinet: Operating environment of 0 to 40° C (32 to 104° F)
• Stainless Steel Cabinet: Operating environment of 0 to 35° C (32 to 95° F)
• IP54 (cabinet only)
